商品の詳細:

起源の場所: 中国広州
ブランド名: LEDKING or OEM & ODM
モデル番号: RO-P391

お支払配送条件:

最小注文数量: 1
価格: $145-165
ベストプライス 連絡先

詳細情報
ピクセルピッチ: 3.91mm ピクセル密度: 65536 Dot/m2
ピクセル構成: 1R1G1B 最大消費電力: 40W
パネル重量: 0.6kg キャビネットサイズ: 500*1000mm*90mm、500*500*90mm
キャビネットの解決: 128点* 256点、128*128点 パネルの数量: 8個、4個
ハブ接続: HUB75-E 最もよい視野角: 170/120
スクリーンの電源: AC110V/220V - 5V60A 最大電力容量: 1200W/平方メートル
平均力: 600 w/m2 輝度: 4000 cd/m2
動作温度: -20℃～60℃
ハイライト:

High Brightness 4000 cd/m2 LED Video Wall

,

100000 Hours Life Span Digital Display Board

,

256*128/256*256 Resolution Outdoor LED Display Screen

製品の説明

Outdoor P3.91 500*500mm Die-Casting Aluminum Rental Advertising Digital Display Board
Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 0
Product Specifications
Module Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Panel Dimension 192mm(W) * 192mm(H) 250mm(W) * 250mm(H) 256mm(W) * 128mm(H)
Pixel pitch 3mm 3.91mm 4mm
Pixel Density 111111 dot/m² 65536 dot/m² 62500 dot/m²
Pixel configuration 1R1G1B 1R1G1B 1R1G1B
Specification SMD1921 SMD1921 SMD1921
Pixel resolution 64 dot * 64 dot 64 dot * 64 dot 64 dot * 32 dot
Max power consumption 30W 40W 32W
Panel weight 0.55KG 0.6KG 0.3KG
Cabinet Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Cabinet size 576mm*576mm*90mm, 768*768*90MM 500*1000mm*90mm, 500*500*90mm 1024mm*768mm*90mm
Cabinet Resolution 192 dot * 192 dot, 256 dot * 256 dot 128 dot * 256 dot, 128*128 dot 256 dot * 192 dot
Quantity of panel 9pcs, 16pcs 8pcs, 4pcs 24pcs
Hub connecting HUB75-E HUB75-E HUB75-E
Cabinet Material Die-casting aluminum cabinet Die-casting aluminum cabinet Die-casting aluminum cabinet
Maintenance Method Front/Back service Front/Back service Front/Back service
Best viewing angle 140/120 170/120 170/120
Screen power supply AC110V/220V - 5V60A AC110V/220V - 5V60A AC110V/220V - 5V60A
Max power capacity 1100 W/m² 1200 W/m² 1550 W/m²
Average power 550 W/m² 600 W/m² 780 W/m²
Technical Specifications
Feature Outdoor P3 Outdoor P3.91 Outdoor P4
Driving IC ICN 2037 / 2153 ICN 2037 / 2153 ICN 2037 / 2153
Scan Rate 1/16S 1/16S 1/8S
Refresh frequency 1920-3840 HZ/S 1920-3840 HZ/S 1920-3840 HZ/S
Display color 4096*4096*4096 4096*4096*4096 4096*4096*4096
Brightness 4500-5000 cd/m² 4000 cd/m² 5500-6000 cd/m²
Life span 100000 Hours 100000 Hours 100000 Hours
Control distance < 100M < 100M < 100M
Best viewing distance 3-30M 3-30M 4-40M
Operating temperature -10°C~45°C -20°C~60°C -10°C~45°C
Operating Humidity 10-90% 10-90% 10-90%
IP protective index IP65 IP65 IP65
>> Most in Kinglight and 3840 refresh rate, if need to change detail and More Pixel Pitch and technical details, feel free to contact us <<
Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 1 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 2 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 3 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 4 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 5 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 6
Company Profile
Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 7 Outdoor LED Display Screen with High Brightness 4000 cd/m2 100000 Hours Life Span and 256*128/256*256 Resolution 8
